Estes Single Stage Rocket Engines: B6-2 (3 ea)

Estes Single Stage Rocket Engines: B6-2 (3 ea)

$19.99 Sale

Overview

The Estes B6-2 engine is single stage engine designed for model rocket flight. This engine is a standard engine designed for flights in rockets weighing less than 4.5 ounces, including the engine. Each package includes 3 engines, 4 starters and 4 plugs.

ATTENTION: Residents of California, New Jersey, Rhode Island and North Dakota please review the Terms of Sale for state specific restrictions or Click Here for State Specific Restrictions.


Estes B6-2 Rocket Engines


Compatible Rockets







Technical Specifications

  • Total Impulse

5.00 N-sec

  • Time Delay

2 Seconds

  • Max Lift Weight

4.5 oz (127 g)

  • Max Thrust

12.10 Newtons (2.7 lbs)

  • Thrust Duration

0.80 Seconds

  • Length

2.8 in. (7 cm)

  • Diameter

18 mm

  • Weight

.61 oz. (17.3 g)

  • Propellant Weight

0.23 oz (6.5 g)


B6 Model Rocket Engine Thrust Curve Chart
