Estes Single Stage Engine: E12-4

Estes Single Stage Engine: E12-4

$39.99 Sale

Overview

The Estes E12-4 engine is 24mm diameter an upper stage engine designed for model rocket flight. This engine can also be used as a single stage engine. Maximum lift weight is 17 ounces. Each package includes 3 engines, 4 starters and 4 starter plugs.

ATTENTION: Residents of California, New Jersey, Rhode Island and North Dakota please review the Terms of Sale for state specific restrictions or Click Here for State Specific Restrictions.




Compatible Rockets







Technical Specifications

  • Total Impulse

30.00 N-sec

  • Time Delay

4 Seconds

  • Max Lift Weight

17.0 oz (482 g)

  • Max Thrust

30.60 Newtons (6.9 lbs)

  • Thrust Duration

2.70 Seconds

  • Length

3.8 in. (9.7 cm)

  • Diameter

24 mm

  • Weight

2.16 oz. (61.2 g)

  • Propellant Weight

1.3 oz (36.9 g)


E12 Model Rocket Engine Thrust Curve Chart
